GVC50-125160 single pole vacuum contactor

AC Contactors

Online consulting：

Product Details

Name						Unit	Data
Main circuit	Rated working voltage (Ue)					V	220、380、1140
	Rated working current (Ie)					A	125、160
	Rated frequency(fr)					Hz	50-60
	Rated making capacity (I)					A	12Ie(AC-4)
	Rated breaking capacity (Ic)					A	10Ie(AC-4)
	Withstand overload current/s					A/s	8 Ie/10
	Power frequency withstand voltage			Phase to earth		kV	4.2
				Vacuum breaks		kV	10
	Lightening impulse withstand voltage					kV	8
Control circuit	Rated voltage (Us)1					V	AC 220

	Rated power (Ps)		Electric holding			VA	≤250/40(attracting/holding)
Auxiliary circuit			type				1a
			Rated value				AC 380V/3A
Rated operating frequency			Long time			Time/h	600
			Short time				3600
Control circuit, auxiliary circuit to earth power frequency withstand voltage						kV	2
Mechanical life						10000 time	30
Electric life						10000 time	6
Mechanical characteristics		Closing time			ms			≤200
		Original opening time			ms			≤160
		Closing tripping			ms			≤10
Remark: 1 rated control voltage can be made according to the requirements of the user;
